product
Ultrasonic Gas Meter
Ultrasound gas meter is a new type of gas metering terminal, which uses the time difference of ultrasonic transmission in the medium to measure the gas flow. It is mainly used to measure the gas flow in the pipeline. It uses the wireless communication technology such as GFSK, LoRa, GPRS, NB-ioT to realize the functions of step gas price, wireless remote transmission, remote valve control, abnormal flow monitoring, etc.The cost of human resources and network deployment for gas companies has been greatly reduced.
Technical parameters
Technical Parameters
ItemUnit specification
RXC02-G1.6
RXC02-G2.5
RXC02-G4
Measuring range   m3/h
0.016~2.50.025~40.04~6
Total Pressure LossPa≤250
Interface center distance mm130
Service temperature℃
-10~40
Accuracy/class 1.5
TightnesskPaInput air 1.5 times the maximum working pressure for five minutes without leakage
Valve Life Cycletimes≥10000
Explosion proof grade/EXib IIBT3 Gb
IP Degree/IP67
Minimum Graduationm30.001
Maximum CurrentmA500


Dimension：

Model / SizeMSLBHDWeight （kg）

RXC02-G1.6

RXC02-G2.5

RXC02-G4

M30×2130203124173.550.51.5


Product size
