product
Ultrasonic Gas Meter
Ultrasound gas meter is a new type of gas metering terminal, which uses the time difference of ultrasonic transmission in the medium to measure the gas flow. It is mainly used to measure the gas flow in the pipeline. It uses the wireless communication technology such as GFSK, LoRa, GPRS, NB-ioT to realize the
Technical parameters
Basic technical parameters
Parameter nameunitType parameter
 RU10-WL-G10
 RU10-WL-G16
RU10-WL-G25
Maximum flowm3/h
16
25
40
Maximum working pressurekPa50
Maximum allowable errormmqmin  ≤ q < qtwhen，±3%
qt  ≤ q ≤ qmaxwhen，±1.5%
Operating temperature℃-10~+40
airtightness/Input 1.5 times the maximum working pressure of air, for three minutes without leakage
Valve lifetime≥10000
Precision class/Level 1.5
Static current

μA

≤50
Operating frequency band

MHz

NB-IoT 800MHz / 900MHz/1800MHz

Wireless transmission power

dBm

≤23


尺寸圖：

Model/sizeMSLBHDquality（kg）

RU10-WL-G6

G2″/φ56.8（11牙/吋）

180

284

212

224.5914.3
RU10-WL-G10
RU10-WL-G16



Product size
